Build Telemetry Container Images¶

Overview¶

Omnia provides src/telemetry/containers/build_images.sh as the entry point for building the telemetry container images maintained in the Telemetry source tree. The script can build all four images or a selected comma-separated set:

This image-build utility is independent of Telemetry domain initialization. It does not create project inputs, run omnia.sh --setup-venv, or deploy the Telemetry stack.

Build selector	Image produced	Default tag	Build source
`kafkapump`	`kafkapump`	`1.3`	Dell iDRAC Telemetry Reference Tools
`victoriapump`	`victoriapump`	`1.3`	Dell iDRAC Telemetry Reference Tools
`telemetry-receiver`	`idrac_telemetry_receiver`	`1.3`	Dell iDRAC Telemetry Reference Tools
`ldms`	`ldms`	`1.1`	The LDMS Containerfile in the Telemetry source tree

The three iDRAC images use a shared checkout of https://github.com/dell/iDRAC-Telemetry-Reference-Tools.git at commit cfa9102a900a76afe9de578d080e98f685625814. The script creates this checkout as src/telemetry/containers/.idrac-telemetry-tools when it is not already present.

The LDMS image uses a multi-stage build based on Ubuntu 26.04. It builds libserdes and OVIS LDMS v4.5.2, installs LDMS under /opt/ovis-ldms, and copies the prepared runner filesystem into the final image.

The builder loads images into the local Podman image store by default. It can instead use Docker Buildx to load images locally or push them to a registry.

Prerequisites¶

Run the procedure from an Omnia source checkout that contains src/telemetry/containers/build_images.sh and the src/telemetry/containers/ldms build context.
Install one of the build tools accepted by the script:
- Podman for the default local build.
- Docker with Buildx for a Docker local build or registry push.
Make git available when building any iDRAC image. The script uses it to clone and check out the pinned iDRAC Telemetry Reference Tools revision.
Provide access to the sources used by the selected build. The iDRAC builds clone from GitHub. The LDMS Containerfile pulls ubuntu:26.04, installs Ubuntu and Python packages, and clones the libserdes and OVIS repositories from GitHub.
For a registry build, use Docker and select a registry location to which the Docker build can push. The script rejects build_action=push with Podman.

Input contract¶

The command syntax is:

./build_images.sh [container] [parameters]

The first argument is the container selector. If it is omitted, the script uses all.

Selector	Result
`all`	Build `kafkapump`, `victoriapump`, `telemetry-receiver`, and `ldms`, in that order.
`kafkapump`	Build only the Kafka pump image.
`victoriapump`	Build only the VictoriaMetrics pump image.
`telemetry-receiver`	Build only the iDRAC telemetry receiver image.
`ldms`	Build only the LDMS image.
Comma-separated selectors	Build each selected image; for example, `kafkapump,ldms`.

Parameters follow the selector and use key=value syntax:

Parameter	Accepted value	Default	Effect
`build_tool`	`podman` or `docker`	`podman`	Selects the container build tool.
`build_action`	`load` or `push`	`load`	Loads the image into the local image store or pushes it. `push` requires Docker.
`registry`	Registry and optional namespace	`docker.io/dellhpcomniaaisolution`	Prefix used for images pushed with Docker.
`kafkapump_tag`	Image tag	`1.3`	Sets the Kafka pump tag.
`victoriapump_tag`	Image tag	`1.3`	Sets the VictoriaMetrics pump tag.
`telemetry_receiver_tag`	Image tag	`1.3`	Sets the iDRAC telemetry receiver tag.
`ldms_tag`	Image tag	`1.1`	Sets the LDMS tag.

Docker builds target linux/amd64. With build_action=load, Docker uses docker buildx build --no-cache --load. With build_action=push, it uses docker buildx build --no-cache --provenance=true --sbom=true --push.

Procedure¶

Change to the telemetry container directory:
Run on: image build host
```
cd src/telemetry/containers
```
Choose one of the following build commands.

To build all four images with Podman and load them locally, run:
Run on: image build host
```
./build_images.sh
```
To build one image or a comma-separated set, provide the selector first:
Run on: image build host
```
./build_images.sh ldms
./build_images.sh kafkapump,ldms
```
To build all four images with Docker and load them locally, run:
Run on: image build host
```
./build_images.sh all build_tool=docker
```
To build all four images and push them to the default registry, run:
Run on: image build host
```
./build_images.sh all build_tool=docker build_action=push
```
To push to another registry location, set registry:
Run on: image build host
```
./build_images.sh all build_tool=docker build_action=push \
  registry=registry.example.com/omnia
```

When required, override the tag for each selected image. For example:

Run on: image build host

./build_images.sh kafkapump kafkapump_tag=1.4
./build_images.sh ldms ldms_tag=1.2

To override several tags in an all build, pass each parameter in the same command:

Run on: image build host

./build_images.sh all build_tool=docker \
  kafkapump_tag=1.4 \
  victoriapump_tag=1.4 \
  telemetry_receiver_tag=1.4 \
  ldms_tag=1.2

Verification¶

Output contract: Verify the build result and image destination.

A successful default all build exits successfully and ends with a build summary containing these image names:

Successfully built: kafkapump victoriapump idrac_telemetry_receiver ldms
All telemetry containers built successfully.

The image destination depends on the selected build mode:

Build mode	Expected images with default values
Podman or Docker with `build_action=load`	`kafkapump:1.3`, `victoriapump:1.3`, `idrac_telemetry_receiver:1.3`, and `ldms:1.1` in the selected local image store
Docker with `build_action=push`	`docker.io/dellhpcomniaaisolution/kafkapump:1.3`, `docker.io/dellhpcomniaaisolution/victoriapump:1.3`, `docker.io/dellhpcomniaaisolution/idrac_telemetry_receiver:1.3`, and `docker.io/dellhpcomniaaisolution/ldms:1.1` in the registry

A custom registry replaces the default registry prefix, and a custom tag replaces the corresponding default tag. The push flow also publishes provenance and an SBOM through Docker Buildx.

The image builder does not write a YAML status file. The Telemetry module's telemetry_status.yml output is written by the deployment workflow, not by build_images.sh.

For a local Podman build, inspect the images that were selected:
Run on: image build host
```
podman image inspect \
  kafkapump:1.3 \
  victoriapump:1.3 \
  idrac_telemetry_receiver:1.3 \
  ldms:1.1
```
For a local Docker build, use the same image names with Docker:
Run on: image build host
```
docker image inspect \
  kafkapump:1.3 \
  victoriapump:1.3 \
  idrac_telemetry_receiver:1.3 \
  ldms:1.1
```
When only a subset was built or tags were overridden, inspect only those images and use their configured tags.
When an iDRAC image was built, verify the revision in the shared source checkout:
Run on: image build host
```
git -C .idrac-telemetry-tools rev-parse HEAD
```
The expected revision is:
```
cfa9102a900a76afe9de578d080e98f685625814
```

Next steps¶

Record the registry and tags used for the build. The Telemetry input manifest represents the three iDRAC images with images.idrac.telemetry_receiver, images.idrac.kafka_pump, and images.idrac.victoria_pump in telemetry_packages.yml.
Be aware of the current LDMS naming difference in the source. The builder produces ldms:<tag>, while telemetry_packages.yml identifies the LDMS sampler as ubuntu-ldms:1.1 and the LDMS chart values request docker.io/dellhpcomniaaisolution/ubuntu-ldms:1.1. The source does not automatically retag or substitute the newly built ldms image. Ensure that the published image name and the LDMS deployment reference are aligned before deploying LDMS.
Configure the required Telemetry inputs, then run the validation and deployment workflow described in Deploy the Telemetry Stack.

Troubleshooting¶

build_action=push requires build_tool=docker: Rerun the build with build_tool=docker, or use the default build_action=load with Podman.
Invalid build_tool or Invalid build_action: Use podman or docker for build_tool, and load or push for build_action.
Unknown container: Use all, kafkapump, victoriapump, telemetry-receiver, or ldms. Separate multiple selectors with commas and do not include spaces.
Unknown parameter: Use only build_tool, build_action, registry, kafkapump_tag, victoriapump_tag, telemetry_receiver_tag, or ldms_tag in key=value form after the selector.
Help is treated as a container name: --help is parsed as a parameter, not as the first positional selector. Run ./build_images.sh all --help to display the script's help.
The iDRAC checkout is not refreshed: If .idrac-telemetry-tools already exists, the script reports that it is already cloned and reuses it without fetching or checking out the pinned revision. Use the revision verification command above to confirm the checkout before relying on a reproducible build.
An image build stops while downloading content: Confirm access to the applicable source listed in Prerequisites. The script and LDMS Containerfile obtain Git repositories, base images, Ubuntu packages, and Python packages during the build.
